ricoh-fi-8150

Ricoh fi-8150 Scanner

Scanning Speed: 50 ppm / 100 ipm (duplex, A4, color, 300 dpi)
Resolution: Up to 600 dpi optical resolution
ADF Capacity: 100 sheets
Daily Duty Cycle: 10,000 sheets
Connectivity: USB 3.2 Gen1, Ethernet (RJ-45)
Supported Paper Sizes: A8 to A4, long document scanning
Output Formats: PDF, JPEG, TIFF, searchable PDF
Image Enhancement: Multi-feed detection, Auto-cropping
Supported Operating Systems: Windows, macOS
Dimensions: 300 x 170 x 163 mm (WxDxH)

Product Highlight

The fi-8150 offers an innovative and superior scanning experience. Compact and reliable, the scanner achieves scan speeds of 50 ppm/100 ipm (200/300 dpi, color, A4 portrait), loads up to 100 sheets at a time, and comes equipped with a capability of scanning up to as many as 8,000 sheets a day.

Scans big volumes with “Automatic Separation Control”

"Paper Protection" function using Image Monitoring technology

Optimized high-quality image data with "PFU Clear Image Capture"

Scans variety of documents including passports and booklets

PaperStream IP and PaperStream Capture providing advanced image processing functions, with PaperStream Capture Pro software as a premium option

PaperStream ClickScan for ad-hoc use

Product Specification

Product Name		fi-8150
Scanner Type		ADF (Automatic Document Feeder) / Manual Feed, Duplex
Scanning Speed^1 (A4 Portrait) (Color^2/Grayscale^2/Monochrome^3)	Simplex	50 ppm (200/300 dpi)
	Duplex	100 ipm (200/300 dpi)
Image Sensor Type		CIS x 2 (front x 1, back x 1)
Light Source		RGB LED x 2 (front x 1, back x 1)
Optical Resolution		600 dpi
Output Resolution^*4 (Color / Grayscale / Monochrome)		50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)^*5
Output Format		Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit
Background Colors		White / Black (selectable)
Document Size	Maximum^*6	215.9 x 355.6 mm (8.5 x 14 in.)
	Minimum	48 x 50 mm (1.9 x 2 in.)
	Long Page Scanning^*7	6,096 mm (240 in.)
Paper Weight (Thickness)	Paper	20 to 465 g/m² (5.3 to 124 lb)^*8
	Booklet	Less than 7 mm (0.276 in.)^*9
	Plastic Card	1.4 mm (0.055 in.) or less^*10
ADF Capacity^1112		100 sheets (A4 80 g/m² or Letter 20 lb)
Expected Daily Volume^*13		8,000 sheets
Multifeed Detection		Overlap detection (Ultrasonic sensor), Length detection
Paper Protection		Image monitoring
Interface	USB	USB 3.2 Gen1x1 / USB 2.0 / USB 1.1
Interface	Ethernet	10BASE-T, 100BASE-TX, 1000BASE-T
Power Requirements		AC 100V - 240V 50/60 Hz
Power Consumption	Operating Mode	21 W or less / 17 W (Eco mode)
	Sleep Mode	LAN: 2.0 W or less USB: 1.4 W or less
	Auto Standby (Off) Mode	0.2 W or less
Operating Environment	Temperature	5 to 35 °C (41 to 95 °F)
Operating Environment	Relative Humidity	15 to 80% (Non-condensing)
Environmental Compliance		ENERGY STAR, RoHS
Dimensions (W x D x H)^*14		300 x 170 x 163 mm (11.8 x 6.7 x 6.4 in.)
Weight		4 kg (8.8 lb)
Supported Operating System		Windows 11^15, Windows 10^15, Windows Server 2022, Windows Server 2019, Windows Server 2016, macOS^16, Linux (Ubuntu)^16
Software / Drivers		PaperStream IP Driver (TWAIN/TWAIN x64/ISIS™), WIA Driver^17, Image Scanner Driver for macOS (ICA)^1718, Image Scanner Driver for Linux (SANE)^1718, PaperStream Capture, PaperStream ClickScan^18, PaperStream NX Manager, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™^*18, Scanner Central Admin Server
Image Processing Functions		Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge filler, Vertical streaks reduction, Background pattern removal, Cropping, Static threshold
Included Items		ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM
